5-PIN SPDT Automotive Relay 40/30A AMP 12V DC 5 Pack Waterproof Starter Relay Kit with Heavy-Duty 12 AWG Tinned Copper Wires, Automotive Cars and Trucks

Nominal Coil Voltage: 12 V DC Coil Power: 1.8 W Coil Resistance: 80 Ω Must Operate Voltage: 6~8 V DC Must Release Voltage: 0.6~3.6 V DC Maximum Applied Voltage: 15.6 V DC Contact Ratings: NO 40A 14V DC Contact Resistance: 100mMAX (at6VDC 1A) Max Switching Current: 40A Max Switching Power: 560 W Life Expectancy Electrical: 100,000 Operations (at30 Operations/minute) Life Expectancy Machanical: 10,000,000 Operations Temperature Range: -30 ~ +80 degrees Celsius Vibration Resistance: 10~55Hz, 1.5mm Shock Resistance: Operations Extremes: 10g. Damage Limits: 100g Hunidity: 40% ~ 85% Insulation Resistance: 100mΩ Min at500VDC Dielectric Strength Between Open Contacts: 500VAC (for one minute/sec) Between Contactw and coil: 750AC (for one minute/sec) Operate Tice: 7ms Release Tice: 5ms Package Content: 5 x 12VDC waterproof relay kit

• The relay adopts pure copper core cable, silver alloy contact, strong conductivity, better stability, and the relay kit adopts high-grade flame retardant materials to ensure safe use and long service life.
• Nominal Coil Voltage: 12 V DC; Coil Power: 1.8 W; Coil Resistance: 80 Ω; Must Operate Voltage: 6~8 V DC; Must Release Voltage: 0.6~3.6 V DC; Maximum Applied Voltage: 15.6 V DC
• Be careful when inserting the relay into the socket. If you force it, you will bend the female connectors,Primary leads use 12 a.w.g tinned copper wire. Coil leads use 16 a.w.g
• These DC waterproof relays and wiring harnesses feature quick-install design for effortless replacement of worn-out relays. This 12V relay engineered with industrial-grade composite housing and high-purity copper coils to ensure optimal conductivity and voltage stability. Our automotive relays are made of longer 12+16 gauge tinned copper wire, which is more resistant to corrosion and oxidation than bare copper wire.
• No reason to return within 30 days, 1-year warranty service; If you are not satisfied with this product, please contact us for an exchange or refund. We hope you will enjoy excellent service.
